Model No: DIN41612-3*32W-M

2.54MM Pitch DIN41612 Connector 396 3 Rows 96PIN PCB Connector Terminal Block Male and Female pcb to Cable Connector

Model Number:DIN41612-3*32W-M
Type:Din 41612 connector
Place of Origin:Guangdong, China
Brand:RealRun
Packaging:Tray
Description:DIN41612 Plug
D/C:AC/DC
Weight:5.55g
Current Rating:Current Rating
Current Resistance(max):30m ohm
Withstand Voltage(for 1 minute):500V /AC
Insulation Resistance(min):1000m ohm
Insulator Flammability:UL 94V-0
Contact materials:Brass
Plating:Gold, Tin, Silver, Ni
Insulator material:LCP +30%Glass Fiber
Operating Temperature range:-40~105

minimum order :

1 piece

Color :

Quantity :

$0.20 - $0.50 / piece

add to cart

Contact Now

Product Description

2.54MM Pitch DIN41612 Connector 396 3 Rows 96PIN PCB Connector Terminal Block Male and Female pcb to Cable Connector

Connector &wiring manufacturers, professional in producing connector&wiring for more than 17 years

We are specialized in electronic connectors, electronic wire harnesses and hardware development,

Name	DIN41612
Pitch	0.8mm/1.0mm/1.27mm/2.0mm/2.54mm/3.96mm/5.08mm
Type	DIP/Angle/SMT Single/Double Row
Insulator Color	Black/Gray/Colorized
Insulator Flammability	UL 94V-0
Current Rating	1.5A AC
Current Resistance(max)	20m ohm
Withstand Voltage(for 1 minute)	500V /AC
Insulation Resistance(min)	1000m ohm
Contact materials	Brass
Contact Plated	Tin or gold over nickel
Insulator material	PBT LCP PA6T PA9T
Packing	PE bag, Tube, Tube+Cap, Tray, Tape & Reel
OEM/ODM	Accepted
